•KIN-TEK的滲透管有兩種基本類型：一次性及可重覆填充。

•種類超過500種化合物

•Modes of Operation: span only

•Flow path suitable for reactive gases – mixture contacts only glass, Teflon® and stainless steel (other materials available)

•Accepts disposable permeation tubes, diffusion tubes, wafer tubes, and prefilled gas fed permeation tubes

•Accepts up to 8 disposable tubes with maximum 6 inch length x 1/4 inch diameter (KIN-TEK HRT, SRT and EL tubes), or　Accepts one of KIN-TEK refillable LFH, or Prefilled 57S

•High mass oven with electronic PID control

•Temperature Control Range: 5 °C above ambient from 30 to 150 °C (heat only)

•Temperature Set Point Resolution: 0.1 °C across control range

•Temperature Display Resolution: 0.1 °C

•Standard Flow Range: 0.25-5.0 standard liters per minute

•Flow Control over Calibrated Range: ≤ ±1.5 % of reading

•Output Concentration Range: below 1 ppb to over 1000 ppm depending on permeation tube emission rate and dilution flow rate

•Power Requirements: Standard: 115 VAC, 2 A

•Power Requirements: Optional (specified at time of purchase): 230 VAC, 1 A

•Dimensions: 6 inch Width x 5 inch Height x 20 inch Depth (add 3.5 inch to Depth for front panel inlet filter clearance)

•Weight: Approximately 27 lbs, shipping 44 lbs
