TYPE: G / H 錶針厚度計

TYPE: G / H

錶針厚度計

DIAL THICKNESS GAGES

廠牌:代理
供應商:大台北尖端儀器有限公司
聯絡電話:02-2531-0981
定價:與我們聯絡

快速詢價

54714

行動條碼QR Code
錶針厚度計-行動條碼QR Code

此產品用途廣泛,,有多款型號可供選擇,適用於各類(物品、產品、小東西零部件、橡膠、氈紙等 ) 之厚度測定,價格優惠中!!

規格

型號

最小讀數

(mm)

測量範圍

(mm)

喉深(mm)

精度(µm)

接觸點

測量壓力

(N)

直徑(mm)

平行度(µm)

G

0.01

0 - 10

20

±20

10

5

1.8

G-MT

0.01

0 - 10

20

±20

10 (金屬)

5

1.8

G-1A

0.01

0 - 10

20

±20

5

5

1.8

G-1M

0.01

0 - 10

20

±20

6

5

1.8

PG-10

0.01

0 - 10

20

±20

10 (金屬)

5

1.8

G-2

0.01

0 - 20

33

±22

10

5

2.0

G-3

0.01

30 (20mm)

20

±20

10

5

1.8

G-4

0.01

65 (55mm)

30

±20

球頭

--

1.8

H

0.01

0 - 10

120

±20

10

5

1.8

H-MT

0.01

0 - 10

120

±20

10 (金屬)

5

1.8

H-1A

0.01

0 - 10

120

±20

5

5

1.8

H-2

0.01

0 - 10

170

±20

球形

--

1.8

H-3

0.01

0 - 10

170

±20

球形

--

1.8


Dial Thickness Gauges 0.01mm type


 These thickness gauges are especially handy for measuring thickness of small parts, metal,
 rubber, vinyl, paper, foil and other sheet material.
The objects to be measured is clamped by simple lever operation.
The measured values are read directly on the dial gauge.
Since the anvil and the contact point are adjusted for parallelism, accurate measured values
are obtained.
Dial Thickness Gauges 0.01mm type
Model G
Graduation 0.01mm
Range 0 - 10mm
Ø10mm flat contact point and
  anvil (ceramic)



G
Model G-1A
Graduation 0.01mm
Range 0 - 10mm
Ø5mm flat contact point and
  anvil (metal)




G-1A
Model G-1M
Graduation 0.01mm
Range 0- 10mm
Ø6mm flat contact point and
  anvil (metal)
The frame on the anvil side
  is cut, which facilitates
  measurement in a narrow place.

G-1M

Model G-2
Graduation 0.01mm
Range 0 - 20mm
Ø10mm flat contact point and
  anvil (ceramic)

G-2
Model G-3
Graduation 0.01mm
Range 30mm (Anvil 20mm)
Ø10mm flat contact point and
  anvil (ceramic)
Anvil side is adjustable
G-3
Model G-4
Graduation 0.01mm
Range 65mm (Anvil 55mm)
Spherical contact point
Anvil side is adjustable

G-4

Model H
Graduation 0.01mm
Range 0 - 10mm
Ø10mm flat contact point and anvil (ceramic)
H
Model H-1A
Graduation 0.01mm
Range 0 - 10mm
Ø5mm flat contact point and anvil (metal)
H-1A

Model H-2
Graduation 0.01mm
Range 0 - 10mm
Spherical contact point and anvil
H-2
Model H-3
Graduation 0.01mm
Range 0 - 10mm
Spherical contact point and roller type anvil
H-3


A PAPER GAUGE "PG-10" is a Thickness gauge to the
Measurement of Paper and similar objects.
Model PG-10 ( Paper Gauge )
Graduation 0.01mm
Range 0 - 10mm
Thickness Gauge to the Measurement of Paper
   and Similar objects.
The gauge is calibrated in 0.01mm or 10 micron.

PG-10 ( Paper Gauge )


Portable size! Excellent usability!
The SK material is used for the
parts holding paper in between

PG-10 ( Example )

The gauge graduation is represented in
millimeter and micron.
Contact Point and Anvil parts available in
special geometry at request.


Specifications
Model Graduation
(mm)
Range
(mm)
Throat depth
(mm)
Accuracy
(µm)
Contact Point Measuring force
less than (N)
Dia (mm) Parallelism (µm)
G 0.01 0 - 10 20 ±20 10 5 1.8
G-MT 0.01 0 - 10 20 ±20 10 (metal) 5 1.8
G-1A 0.01 0 - 10 20 ±20 5 5 1.8
G-1M 0.01 0 - 10 20 ±20 6 5 1.8
PG-10 0.01 0 - 10 20 ±20 10 (metal) 5 1.8
G-2 0.01 0 - 20 33 ±22 10 5 2.0
G-3 0.01 30 (Anvil 20mm) 20 ±20 10 5 1.8
G-4 0.01 65 (Anvil 55mm) 30 ±20 ball tip -- 1.8
H 0.01 0 - 10 120 ±20 10 5 1.8
H-MT 0.01 0 - 10 120 ±20 10 (metal) 5 1.8
H-1A 0.01 0 - 10 120 ±20 5 5 1.8
H-2 0.01 0 - 10 170 ±20 Spherical -- 1.8
H-3 0.01 0 - 10 170 ±20 Spherical -- 1.8
